SL 97

Description of the system:

Bi-folding wood/aluminium system SL 97 has a high level of thermal insulation. System provides three levels of insulation against wind and rain. Aluminium exterior covers protect the wooden profiles from weather influence.

Technical information:

  • Wood/aluminium system
  • Glued wood profile (pine and spruce)
  • Thermally insulated system
  • Bottom-running or top-suspended
  • Construction depth: 96 mm
  • Impermeability to driving rain: up to 7А
  • Resistance to wind load: С3 Air permeability: 3
  • Thermal transmission coefficient: Uw ≥ 0,80 W/ m²K
  • Frame: 45-108 mm Panel: 85/103 mm
  • Sightline: 184 mm
  • Overall frame depth: 96 - 122 mm
  • Overall panel depth: 96 mm
  • Glazing from 24 to 46 mm
  • Dry glazing
  • Frame made of laminated wood with concealed fittings and aluminium outer cover shell between them
  • Three sealing systems for high impermeability
RAL1015
RAL 3011
RAL5003
RAL5008
RAL5014
RAL6005
RAL6009
RAL7004
RAL7006
RAL7015
RAL7016
RAL7021
RAL7024
RAL7035
RAL7038
RAL7039
RAL7040
RAL8017
RAL8019
RAL8022
RAL8077
RAL9001
RAL9003
RAL9004
RAL9005
RAL9006
RAL9007
RAL9010
RAL9011
RAL9016
Solarlux standard colour options include about 30 RAL colours in matt and gloss finishes.
Wood finishes SOLARLUX
